Description
Description:
- Developed for use in all situations
- Long stroke models.
- Single-acting with spring return.
- Manufactured from high-strength, alloyed steel.
- All models have a CR-400 coupler and dust cap.
- MPN #: YRE-101
- Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.
Technical attribute | Metric | Imperial |
Stroke | 250 mm | 9 7/8 inch |
Thread | 2.1/4"-14 UNS | 2.1/4"-14 UNS |
Maximum load | 561 t | 561 US t |
Maximum pressure | 700 bar | 700 bar |
Outside diameter of the cylinder | 57 mm | 2 1/4 inch |
Cylinder height | 350 mm | 13 3/4 inch |
Weight | 6.4 kg |
Advantage
-
Developed for use in all situations.
-
External threads on cylinder head, piston-rod internal threads and mounting threads on the cylinder bottom enable easy assembly (applies to most models).
-
Preloaded return spring increases the entry speed and thus improves performance.
-
The integrated wiper removes impurities on the piston and extends the service life of the cylinder.
KUKKO quality standards
-
Quality made in Germany.
-
Strong design, high performance and long service life.
-
Safety label to ensure protection of intellectual property.
Functionality
-
Hydraulics
-
Accessories
-
Accessories for hydraulic pullers
