Kukko Y-515-6 Separator For Hydraulic Push/Pull Device 13 inch (330 mm)

|
Kukko ToolsSKU: WS03-Y-515-6
filler

Price:
Sale price$5,030.30

Description

Description:

  • For removing ball bearings, roller bearings, inner races and other tight parts if there is not enough space to use pulling hooks.
  • The sharp, wedge-shaped blades of the separator are pressed behind the part to be removed and, in this process, push between the bearing and seat.
  • The wedge-shaped separator jaws are secured underneath the component to be removed.
  • The large supporting surfaces protect the parts to be pulled.
  • The separators of the Y-15 series require the pulling devices of the Y-180 series.
  • MPN #: Y-515-6
  • Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.



Technical attribute  Metric Imperial
Diameter of the shaft 75 - 330 mm 3 inch
Distance of side screw 330 mm 13 inch
Maximum load 30 t 33 US t
Weight 39 kg



Product Data Sheet



Advantage

  • Ultimate stability when removing, as the separator and pulling device are screwed firmly together.

  • Almost all components available as replacement parts, time-saving order process thanks to numbering system.



Functionality

  • Hydraulics

  • Separating
