Description
Description:
- For pulling particularly tight bearings, gears, discs, etc.
- Grease hydraulics.
- Milled thread treated with special coating.
- MPN #: 8-2-M
- Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.
Technical attribute | Metric | Imperial |
Thread length of hydraulic spindle | 350 mm | 13 3/4 inch |
Stroke | 10 mm | 3/8 inch |
Thread | G 1 1/8" | G 1 1/8" |
Maximum load | 20 t | 22 US t |
Maximum torque | 30 Nm | 22 ft lb |
Weight | 11.14 kg |
Advantage:
- Easy and even pulling for particularly tight parts.
- Can be combined with various mechanical pulling devices from the KUKKO range.
- Spindle head band prevents the wrench from slipping off.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system.
Kukko Quality STandard
- Quality made in Germany.
- Strong design, high performance and long service life.
- Safety label to ensure protection of intellectual property.
- A tube of KUKKO special grease included for pressure spindle.
Functionality
- Accessories for External pulling
- Hydraulic pressure screws
- Accessories
