Description
- For removing bearings, gears, discs, etc. for tight or difficult-to-access spaces.
- Automatic tensioning and centering of the extractor jaws.
- Thanks to the integrated force transmission via the spring mechanism, the clamping force increases in proportion to the pulling force.
- Two-arm design for space-saving operation.
- Optimal adjustment of the spindle to the shaft with 2-sided spindle tip (ball and tip).
- Mechanical pressure screw.
- Milled thread treated with special coating
- MPN #: 483-2
- Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.
Technical attribute |
Metric |
Imperial |
Spread | 20 - 85 mm | 3/4 - 3 3/8 inch |
Depth | 90 mm | 4 inch |
Maximum load | 1.5 t | 1.5 US t |
Number of jaws | 3 | 3 |
Weight | 0.425 kg | |
Space below | 5 mm | 3/16 inch |
Space next to it | 12 mm | 1/2 inch |
Advantage
- The elastic effect and slim design enables parts to be pulled in difficult-to-reach places.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system.
KUKKO quality standard
- Quality made in Germany.
- Strong design, high performance and long service life.
- Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).
- Safety label to ensure protection of intellectual property.
- A tube of KUKKO special grease included for pressure spindle.
- Product video on the product can be opened.
Functionality
- Pullers with self-centering jaws
