Description
Description:
- For pulling tight-fitting bearings, gears, discs, etc.
- Swivelling standard puller jaws.
- Two-arm design for space-saving operation.
- 2-jaw and 3-jaw combination cross beam.
- Mechanical pressure screw.
- Milled thread treated with special coating.
- If there is adequate free space around the part to be removed, we recommend using a 3-jaw puller series 47 for optimal distribution of force.
- MPN #: 46-1-B
- Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.
Technical attribute | Metric | Imperial |
Spread | 35 - 300 mm | 1 3/8 - 11 7/8 inch |
Depth | 300 mm | 11 7/8 inch |
Hexagon drive (male) | 36 mm | |
Maximum load | 15 t | 16.5 US t |
Weight | 19.22 kg | |
Space below | 22 mm | 7/8 inch |
Space next to it | 50 mm | 2 inch |
Number of jaws | 2/3 | 2/3 |
Maximum torque | 45 Nm | 33 ft lb |
Advantage
- Combi-pullers can be used as a 3-jaw and 2-jaw puller.
- The larger the pulling force, the stronger the puller hook's grip on the workpiece to be removed.
- Spindle head band prevents the wrench from slipping off.
- Hydraulic spindle series 8 for particularly tight-fitting parts also available as an option.
- Auxiliary hydraulic ram series 9 for particularly tight parts, can be used from a particular puller size.
- Almost all components available as replacement parts, time-saving order process thanks to numbering system
KUKKO quality standards
-
Quality made in Germany.
-
Strong design, high performance and long service life.
-
Safety label to ensure protection of intellectual property.
-
A tube of KUKKO special grease included for pressure spindle.
-
Product video on the product can be opened.
Functionality
-
Pullers with swiveling jaws
