Description
- For use with series 15 and 17 separators.
- The pulling device can be combined with the series 18-0-AS screw adapter to remove parts with threaded holes.
- Mechanical pressure screw.
- Milled thread treated with special coating.
- MPN #:18-5
-
Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.
Technical attribute |
Metric |
Imperial |
Distance of side screw |
150 - 440 mm | 5 7/8 - 17 3/8 inch |
Depth of side screw |
225 - 400 mm | 8 7/8 - 15 3/4 inch |
Thread |
G 3/4" | G 3/4" |
Hexagon drive (male) |
41 mm | |
Maximum load |
20 t | 22 US t |
Maximum torque |
500 Nm | 68.5 ft lb |
Weight |
24.19 kg |
Advantage
-
Ultimate stability when removing, as the separator and pulling device are screwed firmly together.
-
Almost all components available as replacement parts, time-saving order process thanks to numbering system.
KUKKO quality standards
-
Quality made in Germany.
-
Strong design, high performance and long service life.
-
Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).
-
Safety label to ensure protection of intellectual property.
-
A tube of KUKKO special grease included for pressure spindle.
-
Product video on the product can be opened.
Functionality
-
Pulling device
