Description
- For use with series 15 and 17 separators.
- The pulling device can be combined with the series 18-0-AS screw adapter to remove parts with threaded holes.
- Mechanical pressure screw.
- Milled thread treated with special coating.
- MPN #:18-3
-
Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.
Technical attribute |
Metric |
Imperial |
Distance of side screw |
80 - 300 mm | 3 3/16 - 11 7/8 inch |
Depth of side screw |
144 - 300 mm | 5 5/8 - 11 7/8 inch |
Thread |
M18x1,5 | M18x1,5 |
Hexagon drive (male) |
27 mm | |
Maximum load |
10 t | 11 US t |
Maximum torque |
280 Nm | 206.5 ft lb |
Weight |
6.375 kg |
Advantage
-
Ultimate stability when removing, as the separator and pulling device are screwed firmly together.
-
Almost all components available as replacement parts, time-saving order process thanks to numbering system.
KUKKO quality standards
-
Quality made in Germany.
-
Strong design, high performance and long service life.
-
Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).
-
Safety label to ensure protection of intellectual property.
-
A tube of KUKKO special grease included for pressure spindle.
-
Product video on the product can be opened.
Functionality
-
Pulling device
