Kukko 112-20 Universal 2-Jaw Puller for Roller Bearings 5/8 - 3 7/8 inch (16 - 100 mm)

|
Kukko ToolsSKU: WS03-112-20
filler

Price:
Sale price$214.50

Description

  • For removing bearings, gears, discs, etc.
  • Standard pulling hook.
  • Automatic self-centering pulling hooks.
  • Two-arm design for space-saving operation.
  • Mechanical pressure screw.
  • Milled thread treated with special coating.
  • MPN #: 112-20
  • Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.


Technical attribute

Metric

Imperial

Spread 16 - 100 mm 5/8 - 3 7/8 inch
Depth 100 mm 3 7/8 inch
Hexagon drive (male) 17 mm
Maximum load 3 t 3 US t
Maximum torque 55 Nm 40.5 ft lb
Weight 0.945 kg
Space below 5.5 mm 1/4 inch
Space next to it 15 mm 5/8 inch
Number of jaws 2 2



Product Data Sheet

Advantage

  • Quick adjustment of the spread by a knurled cone.
  • Spindle head band prevents the wrench from slipping off.

  • Almost all components available as replacement parts, time-saving order process thanks to numbering system.



KUKKO quality standards

  • Quality made in Germany.

  • Strong design, high performance and long service life.

  • Safety label to ensure protection of intellectual property.

  • A tube of KUKKO special grease included for pressure spindle.


Functionality

  • Pullers with swiveling jaws
