Kukko 110-3 Universal 2-Jaw Puller Techno 3 1/2 - 9 7/8 inch (90 - 250mm)

|
Kukko ToolsSKU: WS03-110-3
filler

Price:
Sale price$388.50

Description

  • For removing bearings, gears, discs, etc.
  • Standard pulling hook.
  • The pulling jaws are consistently straight and equally slim.
  • Pulling hooks with infinitely variable adjustment on the cross-beam.
  • Two-arm design for space-saving operation.
  • Parallel pulling hooks in every position, even with full load.
  • Mechanical pressure screw.
  • Exchangeable spindle top (as from size 110-1).
  • Milled thread treated with special coating
  • MPN #: 110-3
  • Shipping Disclaimer : If the product has to ship directly from the manufacturer it may take 5-7 business days.


Technical attribute

Metric

Imperial

Spread 90 - 250 mm 3 1/2 - 9 7/8 inch
Depth 200 mm 7 7/8 inch
Hexagon drive (male) 22 mm
Maximum load 4 t 6.5 US t
Number of jaws 2 2
Weight 4.88 kg
Space below 18 mm 3/4 inch
Space next to it 35 mm 1 3/8 inch



Product Data Sheet


Advantage

  • Turning the pulling hooks enables them to be used both internally and externally.

  • Spindle head band prevents the wrench from slipping off.

  • Almost all components available as replacement parts, time-saving order process thanks to numbering system.



KUKKO quality standards

  • Quality made in Germany.

  • Strong design, high performance and long service life.

  • Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI).

  • Safety label to ensure protection of intellectual property.

  • A tube of KUKKO special grease included for pressure spindle.


Functionality

  • Puller Economy
